IP Over Coax Converter

IPC-1 IP OVER COAX CABLE CONVERTER (set)

$625.00

Download Specifications < Click here to download the manual in Word 6.0 format. Download Manual
Click here to download the manual in Word 6.0 format. Download “IP Over Coax Issuses” Article

Part Number: IPC-1 (set)
Title: IP OVER COAX CABLE CONVERTER (set)
Category: CCTV SECURITY, DIGITAL PRODUCTS
Industry: CCTV/Security

The IPC-1 allows IP camera signals to travel on existing RG59U or RG6 coaxial cables once used for analog cameras and will extend the operating range of an IP camera far beyond the 100 meter limitation of network cabling over 300 meters up to 1000 Feet. This product is sold as a set.

Product Description

Download Specifications < Click here to download the manual in Word 6.0 format. Download Manual
Click here to download the manual in Word 6.0 format. Download “IP Over Coax Issuses” Article

Part Number: IPC-1 (set)
Title: IP OVER COAX CABLE CONVERTER
Category: CCTV SECURITY
Industry:CCTV/Security

Description:

The IPC-1 allows IP camera signals to travel on existing RG59U or RG6 coaxial cables once used for analog cameras and will extend the operating range of an IP camera far beyond the 100 meter limitation of network cabling over 300 meters up to 1000 Feet.

This equipment operates in full duplex mode without reducing maximum network speed and requires very little installation time with absolutely no set up of IP or MAC addresses so no configuration time is required. You can use this equipment with 10 Mbps signals all the way up to 100Mbps standard Ethernet IP signals. The IPC-1 will pass all forms of error detection and parity signals without interference.

Using this equipment you can over come network cable distance limitations and reach out to areas and locations traditional networking does not allow. Both the 8P8C (RJ45) IP input and the BNC coaxial cable connections are auto-terminated to guarantee proper termination. A bi-colored LED monitors the power supply and the Data signal integrity.

Installation is a snap, just connect one unit at each end of the coaxial cable, then plug your network cables into a unit at each end, then apply power to the units. IP data will begin to automatically communicate and establish the link and then your video will appear at the other end. This unit has easy mounting and a small foot print that helps make it ideal for limited access and tight installations.

IP VIDEO INPUT………….SPECIFICATIONS

Standard………………….All IP Video Standards
Impedance………………..100 Ohms
Connectors………………..8P8C (receptacle)
Data Level…………………800 mVpp
Baud Rate………………….10-100 Mbit

COAXIAL INPUT/OUTPUT

Standard……………………All IP Video Standards
Impedance………………….75 Ohm
Connector…………………..BNC (female)
Data Level………………….1600 mVpp
Baud Rate…………………..10-100 Mbit

NETWORK WIRING

Network Polarity (End to End)….Reverses 1,2 and 3,6 connection (Use T568A for straight applications)

MECHANICAL

Size…………………………..5.50″L X 3.3″W X 2.0″D
Power…………………………24 Volts AC/DC 60mA
Power cube…………………..24 Volts AC (2 included)



Additional Information

Weight 5 lbs
Dimensions 12 x 12 x 6 in
